B4. Inverter (AC Output from DC Battery)
Component ID
300
Part Number
25C300
WBS Code
19.77.01.12.00
Status
Active
Created
2025-01-01
General Description
- Item: DC-to-AC inverter (pure sine wave).
- Purpose: Provide 120 V AC from the battery for small loads.
- Quantity: 1 per home system.
Engineering Specifications
No engineering description available.
Technical Specifications
Technical Specifications
- Power Rating: ~1–2 kW continuous.
- Waveform: Pure sine wave.
- Voltage: 12 V or 24 V input; 120 V output.
- Efficiency: 85–95%.
Compliance Standards
Compliance Standards
- UL 1741 for stand-alone inverters.
- FCC Part 15 (EMI compliance).
Manufacturer Specifications
Manufacturer Specifications
- QR Code: On chassis or package.
- Burn-In Test: 100% load for 30 minutes recommended.
- Packaging: Foam corners, double-wall box.
