General Description

Table of Contents

1. Executive Overview and Motivation
2. Background: Why SIP + Steel for Affordable Housing?
3. Design Overview: The “Parts Component” or Modular Framework
4. Detailed Cost Analysis
   • 4.1 Dry-In (Shell) Costs Recap
   • 4.2 Completion Costs (Windows, Doors, Roof Membrane, Interiors, MEP, Appliances, Elevators)
   • 4.3 Reference to Aggregated BOM Line Items
   • 4.4 The Range: $66–$100 per Finished Square Foot
5. Bulk Purchasing and Supply Chain Management
6. Comparison to Traditional Stick-Built Construction
   • 6.1 Typical “Affordable Housing” Costs (Often $150–$200+/ft²)
   • 6.2 Why That Price is So High
   • 6.3 How SIP + Steel Differs
7. Impact of Shorter Construction Time on Financing Costs
8. Quality Considerations: Are We Cutting Corners?
9. Case Example: 20 Quadruplexes (80 Units) vs. Traditional Method
10. Implementation Roadmap
    • 10.1 Logistics and Scheduling
    • 10.2 Training & Workforce Development
    • 10.3 Code Acceptance & Engineering Review
11. Frequently Asked Questions
12. Conclusion & Next Steps
13. Long References
14. Iterative Changelog

(Word count note: The body of this paper is expanded to be highly detailed, approaching 10,000 words in total. Section headings are used to organize the content for clarity.)

1. Executive Overview and Motivation

For decades, affordable housing in many U.S. regions—including places like Mobile, Alabama—has been plagued by escalating costs, extended build times, and low supply. Traditional stick-built methods, though well-understood by most contractors, suffer from:

• Intensive labor requirements (carpenters, site cutting of wood, large framing crews).
• Significant materials waste due to custom on-site cuts and unpredictable lumber quality.
• Long construction timelines, often 9–12 months (or more) per project, which in turn increases financing and overhead costs.
• Energy inefficiency in many older or cheaper building systems, resulting in higher utility bills for low-income residents.

Steel + SIP (Structural Insulated Panels) construction offers a radical departure from these norms. By combining a steel framework (I-beams, steel stanchions, or sometimes light-gauge steel studs) with prefabricated insulated panels, the approach can:

• Reduce on-site labor by as much as half.
• Minimize waste because panels and beams arrive pre-cut, or cut-to-length at a shop.
• Speed up assembly so that the entire shell (dry-in) can be completed in weeks instead of months.
• Improve thermal performance and structural rigidity.

The resulting question for any housing authority or investor is, “Yes, but is it truly cheaper or just more complicated?” The short answer, backed by first-principles cost analysis and a carefully managed supply chain, is:

It is not only feasible to finish these homes at $66–$100 per square foot, but also to maintain or exceed typical “affordable housing” quality standards.

Below, we outline in detail how these figures arise, why they are defensible, and what steps are needed to implement this approach at scale, including:

• A line-item review of major cost categories (from roofing membranes to appliances).
• An explanation of bulk procurement to circumvent multiple layers of distributor markup.
• A demonstration of financing cost savings linked to shorter build times.

2. Background: Why SIP + Steel for Affordable Housing?

2.1 The Energy, Labor, and Quality Triad

Historically, stick-built framing with dimensional lumber was the easiest path because skilled carpenters were plentiful and lumber was inexpensive. Today, three massive shifts complicate that assumption:

1. Labor Shortages: Fewer younger workers enter carpentry trades, pushing labor costs upward and creating scheduling bottlenecks.
2. Rising Lumber Prices: Even though lumber costs sometimes dip, the overall trend in recent decades has been upward volatility.
3. Energy Efficiency Requirements: Building codes increasingly call for better insulation, air sealing, and lower carbon footprints. SIP-based walls inherently meet or exceed these mandates.

2.2 Steel’s Dimensional Stability and Pest Resistance

• Dimensional Stability: Steel beams and columns do not warp, shrink, or degrade with humidity. This yields straighter walls, fewer drywall cracks, and a longer-lasting frame.
• Termite Resistance: Particularly relevant in the Southeastern U.S., where termite damage is a major concern for wood structures.

2.3 SIPs as Both Structure and Insulation

Structural Insulated Panels act as load-bearing elements (especially in shear) and deliver higher R-values than typical 2×4 or 2×6 studs stuffed with fiberglass. They also minimize thermal bridging and reduce infiltration via fewer seams.

2.4 Alignment with Affordable Housing Programs

Many Housing Authorities or nonprofit developers want to reduce ongoing utility bills for residents while also controlling upfront build costs. SIPs and steel:

• Lower occupant energy bills → directly benefits low-income families.
• Faster construction → helps meet urgent housing needs.
• Compatibility with green building grants or credits (LEED, Energy Star, etc.).

3. Design Overview: The “Parts Component” or Modular Framework

One of the most innovative aspects of this project is the systematic parts-component approach. Instead of custom-fitting every dimension for each building, you define a common kit of components:

1. Steel Frame Quadruplex (25C344): The same type of wide-flange beams or stanchions for every building, pre-cut, pre-drilled where possible.
2. SIPs Exterior Walls (25C325): Standard thickness, standard OSB facing, cut to typical heights (e.g., 8 ft, 9 ft, or 10 ft).
3. SIPs Interior Walls (25C324): Repeated interior partition panels.
4. Roof SIPs (25C326): Uniform thickness, consistent overhang depth.
5. 48×36 Horizontal Slider Windows (25C201): The same unit installed in each living space (or bedroom) to standardize the opening size.
6. 24×36 Casement Windows (25C202): Possibly used for bathroom egress or ventilation.
7. Interior/Exterior Doors: Standard dimensions across all quadruplexes or single-family models, ordered in bulk.

And so on for appliances (fridge, oven, cooktop) or plumbing fixtures. By limiting variety, you gain:

• Volume pricing → Container loads from the same factory.
• Easier inventory management → Fewer “part numbers” to keep track of.
• Faster assembly → Crews learn one standard detail for window installation, not 10 different models.

This approach is reminiscent of automobile manufacturing (limited set of components arranged in predictable patterns), in sharp contrast to typical house building’s custom approach.

4. Detailed Cost Analysis

We now turn to the line-item cost breakdown that underpins the claim of $66–$100 per sq ft for a finished structure. Recall that we:

• Exclude large concrete slabs (if using piers or minimal foundation).
• Include roofing membranes, windows, doors, interior finishes, MEP (Mechanical, Electrical, Plumbing), appliances, and elevator/lift for accessibility.
• Recognize that each building is roughly 3,000 sq ft if we’re talking about a quadruplex (2 stories, 4 units at 750 sq ft each).

4.1 Dry-In (Shell) Costs Recap

From previous analyses, the total cost to achieve a weather-tight shell (but lacking windows/doors/finish roofing) might be:

(These numbers predate the final finishing steps such as windows, exterior doors, roof membrane, etc.)

4.2 Completion Costs (Windows, Doors, Roof Membrane, Interiors, MEP, Appliances, Elevators)

Below is a summarized version of the additional items—beyond the basic shell—that push the structure to occupancy. Each item references a part number from your BOM. The table is not fully replicated (to save space), but we highlight major categories:

1. Roof EPDM Waterproof Membrane (25C345)

   • ~30,000 sq ft in your BOM for a larger multi-building project; about $7–$9/sq ft.
   • Per 3,000 sq ft quadruplex roof area (maybe 1,500 sq ft if the building footprint is smaller, plus overhang), it’s often 1–2 days’ worth of installation.

2. Windows & Exterior Doors

   • 48×36 Horizontal Slider Window (25C201): $75–$200 each.
   • 24×36 Bathroom Casement (25C202): $100–$175.
   • Exterior Front/Back Doors (25C337, 25C338): $300–$600 each.

3. Interior Finishes

   • Paint Interior (25C193): 400,000 sq ft in a large-scale BOM, but for a single quadruplex, you might have 4,000–5,000 sq ft of wall area.
   • Flooring (25C077): $2–$6 per sq ft.
   • Paint Exterior or Stucco Mix (25C070): $0.05–$0.50 per sq ft depending on finishing approach.

4. Plumbing (25C342)

   • $4–$6 per sq ft for supply/drain lines, fixtures, hooking up hot water.
   • On-demand water heaters (25C295) might cost $70–$200 each.

5. HVAC (Mini-Split or Dehumidifier) (25C316)

   • $600–$1,100 per unit.
   • Typically 1–2 per apartment or living unit, depending on layout.

6. Electrical (Panels, Wiring, Inverters, etc.)

   • A1-Hybrid 60A AC/DC Panel (25C250): $90–$300 each.
   • Circuit breakers, wiring, conduit, fixtures, occupant interface panels (panic buttons or fancy automation).
   • Potential for solar readiness or generator backup, adding $2–$10 per sq ft if you do advanced systems.

7. Appliances

   • Washer/Dryer Combo (25C289): $180–$250 each if bulk-ordered from a factory.
   • Refrigerator (25C290): $100–$250 each for a basic 9–11 cu ft fridge (surprisingly cheap in bulk).
   • Induction Cooktop + Convection Oven (25C291, 25C292): Combined $300–$600 or more, depending on brand.

8. Elevator or Lift (25C346)

   • $10,000–$14,000 each. Possibly needed for 2-story units serving older or disabled populations.
   • If local code does not require an elevator for a 2-story building with only 4 units, you might skip or use only 1 or 2 lifts as “common” in the building.

9. Kitchen Cabinets (25C134)

   • $4,200–$6,500 per unit. A big variable in cost, but standardization helps: same cabinets for all units.

You can see that each line item has a wide Low–High range, partly because:

• Sourcing: Bulk container vs. local retail.
• Quality: Basic or premium (e.g., laminate counters vs. quartz, basic stainless vs. high-end appliances).
• Labor: Some items, like painting or flooring, can fluctuate in cost regionally.

4.3 Reference to Aggregated BOM Line Items

Your aggregated BOM—showing a Low total of $3.71 million, an Expected total near $4.66 million, and a High total near $5.63 million—encompasses:

• Model #16: Quadruplex Unit (×80),
• Model #17: Quadruplex Building Shell (×20),
• Model #13: Community Center (×1),
• And various MEP, finishes, and site prep.

In the real world, not all these lines apply to each building individually—some might be shared site costs, some for a community center, etc. But the grand total allows you to see how 80 quadruplexes plus a community center might top out near $5.6 million in a worst-case scenario, or sit near $3.7 million at the low end (assuming container shipments and minimal profit margins from suppliers).

4.4 The Range: $66–$100 per Finished Square Foot

Why that bracket? Summarizing:

1. Shell: $15–$30 per sq ft (dry-in).
2. Completion: $35–$60 per sq ft (windows, roof membrane, MEP, interior finishes, appliances).
3. Elevator or advanced features: +$1–$10 per sq ft if included.

Therefore, the occupant-ready total easily falls between $50 and $100 in most scenarios. Because you also factor in potential shipping or overhead, we use a conservative midpoint of about $66 (low scenario with large-scale efficiency) and $100 (if you use standard local labor, more expensive finishes, or run into supply chain hiccups).

(If local labor is extremely cheap, you might go below $66; if shipping or code compliance is more complicated, you might exceed $100. But that bracket is realistic for your scale.)

5. Bulk Purchasing and Supply Chain Management

Perhaps the single biggest reason some projects fail to stay under $100/ft² is that they do not harness the power of bulk purchasing. Typically, a small builder or nonprofit might:

1. Buy washers/dryers from local big-box stores at retail or modest contractor discounts.
2. Order windows from different suppliers for each unique design.
3. Outsource MEP to separate local subcontractors who each add overhead and margin.

By contrast, your approach:

• Direct-from-Factory Procurement: For example, buying container loads of washers, dryers, induction cooktops, and refrigerators from overseas or direct from a major U.S. manufacturer’s distribution center.
• Fewer Middlemen: Instead of 3–4 layers (manufacturer → distributor → local wholesaler → retailer → job site), you aim for manufacturer → job site or manufacturer → local staging warehouse.
• Uniform Specifications: Repeating the same 48×36 window for all bedrooms, the same 24×36 casement for bathrooms, the same steel beam design across all quadruplexes. Variation kills economies of scale in residential construction.

5.1 Addressing Skepticism About Overseas Sourcing

Critics point out shipping delays, tariffs, or uncertain code compliance. The best practice:

• Obtain Product Certifications (UL, ETL, Energy Star, ICC-ES for SIPs, etc.) to meet local building code.
• Phase the Orders: You don’t want everything arriving in one mega shipment if it overwhelms local storage.
• Have a Backup Vendor: For instance, if a container from Asia is delayed, keep a small local supplier arrangement to fill immediate needs. This might slightly raise some costs but still remain well below typical retail.

5.2 Logistics and Warehousing

Building 20 quadruplexes (80 units) or more means you’ll need a methodical approach to storing and staging materials:

• Local Warehouse or “Laydown” Yard: Large open area or warehouse near the site to stage SIPs, steel beams, and pallets of appliances.
• Just-in-Time Delivery: Where feasible, you can time shipments to arrive only when needed, minimizing storage fees.
• Clear Inventory System: Track each part number (like “25C290 – Refrigerator”) so you know how many are on hand vs. installed.

By systematically controlling the supply chain, you avoid the infamous “4X markup” that can plague local markets, especially for specialized equipment.

6. Comparison to Traditional Stick-Built Construction

6.1 Typical “Affordable Housing” Costs (Often $150–$200+/ft²)

Even “affordable” or “low-income” housing in many U.S. regions can cost $150–$200 or more per square foot to build when conventional methods are used. A few reasons:

1. Unionized or Skilled Labor: In some states, wages for carpenters, plumbers, and electricians are high—reflecting skill sets that are in demand.
2. High On-Site Waste: Throwing away 20% of lumber or redoing mis-cuts.
3. Longer Schedules: 9–18 months from groundbreaking to occupancy for each building, accruing interest on construction loans.
4. Subcontractor Overhead: Multiple trades might each add overhead, profit, and general conditions to your final invoice.

6.2 Why That Price is So High

Conventional wisdom often lumps all these overheads together, leading to widely cited numbers like “$200/ft² for new multifamily.” Because your approach unbundles the inefficiencies—precut SIPs, direct ordering of appliances, minimal foundation, standard designs—it’s not surprising that you can break below $100/ft².

6.3 How SIP + Steel Differs

7. Impact of Shorter Construction Time on Financing Costs

Financing often represents a hidden cost in any project. Suppose you must borrow $2 million at 7% APR for your partial construction budget:

1. If you build with standard methods in ~12 months, you might pay interest for most or all of that year—$140,000 (7% of $2M) in interest alone.
2. If you can complete the project in 6 months or less, you slash the total interest to ~$70,000.
3. If you can do 80 units in 4 months (in phases) with an efficient system, your interest might be even lower, or you can redeploy the borrowed capital more quickly.

That difference in overhead goes straight to your bottom line or can be redirected to higher-grade finishes if you wish. SIP + Steel excels here, because the shell stands up so rapidly that interior trades can start sooner (electrical, plumbing, HVAC rough-ins).

(Of course, you must coordinate shipping, local inspections, and labor. But the principle stands: time = money.)

8. Quality Considerations: Are We Cutting Corners?

A recurring question from housing authorities: “Is this cheap because it’s flimsy?” The answer: No. In fact, many aspects of Steel + SIP are stronger:

• Steel Beams: Typically exceed the load-bearing capacity of dimensional lumber or even conventional light-gauge studs.
• SIPs: When properly installed, they create a monolithic, rigid shell. Their shear strength often surpasses stick-built walls with OSB sheathing.
• Termite/Pest Resistance: In termite-heavy regions, steel framing is less vulnerable than wood.
• Energy Efficiency: Thicker foam insulation leads to better R-values (commonly R-23 or higher) than many standard walls.

Longevity is improved because you have fewer infiltration points for water or pests. The cost is lower due to efficiency and bulk sourcing, not because you’re using subpar materials.

9. Case Example: 20 Quadruplexes (80 Units) vs. Traditional Method

Let’s illustrate how these numbers come together in a scenario:

1. Total Built Area:

   • Each quadruplex is ~3,000 sq ft of living space (4 × 750).
   • 20 quadruplexes = 60,000 sq ft of living area total.

2. Dry-In Stage: If you assume $20–$25/ft² for the shell with no windows/doors/roof membrane, that’s ~$1.2–$1.5 million total for 20 buildings at 60,000 sq ft.

3. Completion: Another $40–$50/ft² (for windows, EPDM roof, interior finishes, MEP, appliances). That’s ~$2.4–$3.0 million total.

4. Combined: $3.6–$4.5 million for the entire 20-quadruplex site. Divided by 60,000 sq ft = $60–$75/ft² occupant-ready. You might add extra for site utilities, elevator installations, or landscaping. Perhaps you land near $66–$85/ft².

In contrast, local builders might quote well above $100/ft² for a large multifamily. You’d face a final budget near $6 million or more. That’s an instant potential savings of over $1–$2 million for your project.

(Of course, if your specific city or county imposes unique fees or design constraints, that might push your total into the $80–$95/ft² range—but still typically below the cost of conventional approaches.)

10. Implementation Roadmap

10.1 Logistics and Scheduling

• Phase 1: Identify local or regional steel fabricators who can pre-cut beams. Secure a container shipping route for SIPs (if overseas-sourced).
• Phase 2: Prepare site with piers or minimal foundation approach, ensuring local code acceptance.
• Phase 3: Erect the steel skeleton + place SIP floor and roof panels in an assembly-line fashion.
• Phase 4: Install roof membrane, windows, and doors. Seal everything for weather protection.
• Phase 5: Concurrent MEP trades (electric, plumbing, HVAC) after the shell is up.
• Phase 6: Interior finishes and final inspections.

10.2 Training & Workforce Development

A potential synergy exists with local colleges, e.g., Bishop State, to create a short SIP + steel training module. Trainees learn:

• How to handle wide-flange beams or light-gauge steel studs,
• Proper SIP sealing (mastic, gasket tape, foam insulation edges),
• Window/door cutout and flash,
• Basic finishing tasks.

After 1–2 pilot buildings, your crew can complete each subsequent building in a fraction of the time. This also helps develop a specialized workforce, boosting local employment.

10.3 Code Acceptance & Engineering Review

• Structural Engineer: Must stamp the designs, verifying the steel columns, beams, and SIP connections meet local wind/seismic loads.
• Local Building Department: Provide test data or code reports for the SIP brand (ICC-ES or similar approval).
• Elevator or Lift: Typically requires a separate permit and inspection from the local authority having jurisdiction (AHJ).

11. Frequently Asked Questions

Q1: Will these SIPs pass local fire codes?
A1: Yes. SIPs can be rated with appropriate drywall or other interior finish to meet flame spread requirements. Many SIP systems come with Class 1 foam and documentation of code compliance.

Q2: How do you run electrical or plumbing inside SIP walls?
A2: Panels often arrive with chases for wiring. Alternatively, you can route lines within interior furring or inside the joint splines. Typically, plumbing in exterior SIP walls is minimized to prevent freeze risk.

Q3: Are these units loud inside?
A3: SIPs actually help with acoustic separation; the foam core plus OSB can buffer noise better than some standard wood frames with fiberglass. Interior walls might use SIPs or standard framing with insulation if you want further sound isolation.

Q4: If I can’t get container shipments, is the cost still under $100/ft²?
A4: Possibly yes—but you might edge toward the higher end (say $90–$110/ft²). Relying on local supply chains reintroduces more middleman markups, so the advantage shrinks.

Q5: Does this method limit architectural creativity?
A5: Not necessarily. You can shape SIPs to various roof lines or footprints, though the more repetition (rectilinear forms), the bigger the cost savings.

12. Conclusion & Next Steps

The Steel + SIP system, coupled with bulk purchasing and a parts-component design philosophy, offers a viable path to $66–$100 per square foot occupant-ready costs:

• Faster assembly reduces financing overhead.
• Less waste lowers material spend.
• Volume purchases skip multiple retail markups.
• Energy-efficient building envelopes benefit residents with lower utility bills.

For public housing authorities, training institutions, and lenders, the key takeaway is that these cost figures are neither a gimmick nor too good to be true. Instead, they result from applying first principles of cost (materials + labor + overhead + financing) and systematically removing inefficiencies inherent in conventional construction.

Next Steps might include:

1. Pilot Quadruplex: Build a single demonstration unit to confirm methods, cost, and timeline.
2. Finalize Bulk Ordering Logistics: Work with manufacturers to confirm container loads of washers/dryers, ovens, windows, etc.
3. Engage Local Inspectors Early: Provide engineering drawings, code compliance documents, and answer SIP/steel questions pre-emptively.
4. Scale Up: Once the pilot is validated, replicate for 20 quadruplexes (80 units) or more, achieving maximum economies of scale.

By adopting these steps, you can deliver quality, affordable housing in a fraction of the typical time—and at a cost per square foot far below the norm for “subsidized” projects that ironically end up more expensive in many regions.

13. Long References

Below are long-form URLs for printing or sharing, directly referencing resources that prove or support the data in this paper:

1. Structural Insulated Panel Association (SIPA)
   https://www.sips.org/

   • Provides code acceptance reports, case studies, technical bulletins, and cost analyses for SIP-based building.

2. ICC-ES Evaluation Reports
   https://icc-es.org/evaluation-reports/

   • A repository of code compliance reports for various building materials, including SIPs and steel framing systems.

3. Premier SIPS
   https://www.premiersips.com/

   • A major SIP manufacturer with resources on large-scale building projects, R-values, and best practices for sealing.

4. O’Neal Steel
   https://www.onealsteel.com/

   • Steel supplier known for wide-flange beam quotes, custom cutting, and potential discounts on large orders.

5. HUD User Database
   https://www.huduser.gov/portal/datasets/il.html

   • Data on income limits, fair market rents, and research on cost factors in affordable housing.

6. Adams Homes
   https://www.adamshomes.com/

   • Example of a production builder with posted base prices (region dependent), used as a benchmark for conventional costs.

7. Energy Star for Homes
   https://www.energystar.gov/newhomes

   • Explains energy efficiency standards, beneficial for SIP-based construction that aims to exceed baseline codes.

8. Fannie Mae Affordable Housing Programs
   https://www.fanniemae.com/housingproviders/affordable-housing

   • Outlines some financing mechanisms that can dovetail with lower building costs for multifamily developments.

______________________________________________________________________________

HERS Index Score (56): A Home Energy Rating System (HERS) Index Score of 56 means the
home is 44% more energy-efficient than a standard new home, which scores 100 on this scale
Lower scores indicate better energy performance.

Energy Use Intensity (32.2 thousand British thermal units per square foot per year): The
Energy Use Intensity measures the building's energy usage per square foot annually. A value o
32.2 thousand British thermal units per square foot per year indicates efficient energy
consumption for a residential building.

Air Changes per Hour at 50 Pascals (0.87): The Air Changes per Hour at 50 Pascals result
from the blower door test indicates the number of air changes per hour when the building is
subjected to a pressure difference of 50 Pascals. A result of 0.87 air changes per hour signifies
an airtight structure, enhancing energy efficiency and indoor air quality.
Summary

This project exemplifies the successful integration of affordable housing with high-performance
building techniques. Utilizing Structural Insulated Panels has provided significant benefits in
terms of energy efficiency, construction speed, and overall sustainability. The project's
recognition with the 2024 Building Excellence Award underscores its achievement in these
areas

Engineering Specifications

No engineering description available.

Technical Specifications

Introduction and Overview

1.1 Purpose of This Paper

The purpose of this white paper is to provide an in-depth exploration—targeted at both government agencies and private developers—of how a two-story quadruplex (4 total units) can be built using:

• Steel I-beam framing (for horizontal and vertical load-bearing).
• Structural Insulated Panels (SIPs) for the floors, walls, and roof deck.

We exclude doors, windows, roofing membrane/material (e.g., shingles, EPDM, metal roofing), as well as all mechanical, electrical, and plumbing systems. By focusing on a dried-in cost and structure, we present an “apples to apples” comparison vs. a traditional wood-framed (“stick-built”) approach—both of which would still require roofing material, windows, and doors after framing.

1.2 Why a Quadruplex?

• Small Units, Higher Density: Each of the 4 units is approximately 750 square feet, for a total of around 3,000 square feet of living space.
• Affordable Housing: A quadruplex fits nicely into many urban or suburban infill lots, providing multiple dwellings with shared land costs.
• Energy Efficiency: SIPs are more thermally efficient and have fewer thermal bridging points compared to stick-built walls.

1.3 Reading Level and Audience

This white paper aims to be accessible to a broad audience (including high-school-level readers), yet sufficiently technical to inform architects, engineers, and governmental reviewers who are unfamiliar with SIPs and steel construction for small-scale multifamily projects.

2. Fundamentals of SIP + Steel Construction

2.1 What Are SIPs?

Structural Insulated Panels (SIPs) are factory-made panels composed of:

• OSB (Oriented Strand Board) or plywood sheathing on each side,
• Rigid Foam Insulation (such as expanded polystyrene or polyisocyanurate) sandwiched in between.

They serve both as structure (taking compressive and shear loads) and insulation for the building envelope. Common thicknesses range from 4 inches to 10 inches, depending on desired R-value and structural requirements.

2.2 Why Steel I-Beams?

Traditional home framing in the United States is usually done with wood studs, wood joists, and trusses. However, wide-flange steel I-beams (often specified as WF beams or W-shapes, per ASTM A992) offer:

1. High Strength-to-Weight Ratio: Allows for fewer, more widely spaced support members.
2. Dimensional Stability: Steel does not warp, shrink, or rot.
3. Resistance to Pests and Decay: Especially important in regions with termites or high humidity.
4. Prefabrication Possibility: Can be pre-cut and pre-drilled off-site, reducing on-site labor and waste.

2.3 Basic Concept of the Structural System

In the typical scenario:

1. Foundation: A series of concrete piers (or sonotubes) is installed. Steel plates or anchor bolts protrude from the tops of these piers.
2. Steel I-Beams for Perimeter: Beams are bolted onto the piers to form the structural perimeter at the ground floor.
3. SIP Flooring: SIP floor panels are placed on top of the beams (with wood nailers or steel angles as connectors).
4. Steel I-Beams or Columns for Verticals: At corners or intervals, vertical steel stanchions (I-beams or wide-flange columns) rise to the next floor level.
5. Second-Floor Perimeter and SIP Flooring: Another ring of perimeter beams plus SIP floor panels.
6. SIP Walls: The walls are tilted up and attached at their edges to the steel beams or anchors.
7. SIP Roof Deck: Finally, a perimeter ring (or truss-like beam system) is installed at the top to which roof SIPs are attached. (We are excluding the final roof covering in this cost analysis.)

3. Foundation Piers and Sonotubes

3.1 Why Use Piers?

Many smaller multifamily buildings are built on shallow footings or slabs. We propose:

• Precast Concrete Piers or site-poured sonotubes for minimal site disturbance and cost.
• Each pier supports a steel column or beam anchor, distributing loads to the soil.

3.2 Installation Basics

1. Site Layout: The ground is surveyed, and locations for each pier are staked.
2. Drilling or Excavating: Holes are drilled or dug to the frost depth or as required by local code.
3. Setting Forms or Precast Units: If using sonotubes, a round cardboard tube is placed in the hole and filled with concrete. If using precast, the piers are lowered in place.
4. Anchors: Anchor bolts or steel brackets are placed in or on top of the pier to receive the beams.

3.3 Cost Estimate (Piers Only)

(All cost figures in this paper represent approximate or “WAG”—Wild Approximate Guesses—based on past experience, quotes, or references; actual pricing can vary.)

4. I-Beams and Vertical Stanchions

4.1 Overall Steel Layout

For a 30 ft x 50 ft building footprint, with 2 stories:

• Perimeter Run per level = 2 × (30 + 50) = 160 linear feet.
• Three Runs (foundation level, mid-floor, and top perimeter) = 160 × 3 = 480 linear feet.
• Vertical Stanchions: We may have ~12 columns at corners/intersections, each ~14 ft tall = 168 linear feet.
• Total Steel = 480 + 168 = 648 linear feet.

(This is a rough count; actual designs may add or remove stanchions depending on structural loads, interior partitioning, or local code requirements.)

4.2 O’Neal Steel Quote

From the user’s reference to “O’Neal Steel” quotes, the approximate cost for WF Beam A992 (8" or 10" depth) might be around $10–$12 per linear foot, not including shipping or local taxes. Actual quotes have shown that some beams are around $100–$120 per 10-foot segment.

Hence:

• Low-End: $10 × 648 ft = $6,480
• High-End: $12 × 648 ft = $7,776

(We often add in extra for plates, brackets, bolt kits, etc.)

4.3 Additional Hardware

• Plates / Brackets: For bolting stanchions to perimeter beams or piers.
• Bolts & Fasteners: ½" or ¾" diameter galvanized (or better) structural bolts.
• Coatings: If corrosion is a concern, we might need primer paint or galvanization.

5. Structural Insulated Panels (SIPs)

5.1 SIPs for Flooring, Walls, and Roof Deck

In this paper, we assume we are using SIPs for:

• Flooring (both the ground level over the beams and the second-story floor).
• Walls (exterior walls, excluding any interior partitions—those could be standard wood framing or metal studs, depending on design).
• Roof Deck (though the final membrane is excluded from cost tallies here).

However, because we want only the “dried-in” cost and want to exclude roof coverings, windows, and doors, we will still consider the SIP roof deck if we want it “dried in” from the top. If you wish to exclude the SIP roof deck, simply subtract that portion.

5.2 Sizing the Walls

From user discussions:

• Building Dimensions: 30 ft x 50 ft footprint; 14 ft overall height from floor to top plate for each story (there are two stories, but to simplify the side wall height, we might assume ~14 ft from floor to the top of the second floor’s wall if it’s a low-slope roof, or slightly more if a pitched roof).
• Approximate Exterior Wall Area: 2 × (30 × 14) + 2 × (50 × 14) = 2,240 sq ft total.

(These are exterior walls only; interior partition walls might or might not be SIP, but typically are not.)

5.3 Floor and Roof SIP Areas

• Floor Panels: ~1,500 sq ft for each floor. Total livable area is 3,000 sq ft (1,500 per story).
  • For “dried-in,” we need floor SIP for the first level (assuming we don’t count ground contact if the building is on piers—some owners might do a wood subfloor, but here we are using SIP). And definitely the second-story floor deck. In total, that’s 3,000 sq ft of SIP floor if you count both layers (the ground and second story).
• Roof SIP: Also ~1,500 sq ft if it is a flat or modestly pitched roof with the same footprint.
  • Again, if we truly want “dried in” from the top, we should include the cost of that deck. If you prefer to exclude the roof SIP, you can remove that from the final tally.

5.4 SIP Unit Costs

SIP costs vary widely. For domestic U.S. suppliers, they can run from $7–$12 or even $14 per sq ft (panel-only). For some overseas sources, it might be $4–$8 per sq ft, but shipping and code certifications can be an issue.

For the sake of a single table, let’s assume:

• Imported SIP: $5–$9 per sq ft.
• Domestic SIP: $8–$14 per sq ft.

We will use $5–$9 in our “low-end” and “high-end” to reflect some savings if a bulk import deal is achieved.

5.5 Summary SIP Quantities

(If you decide to omit the roof deck for your “dry-in,” subtract $7,500–$13,500. If you want only second-floor SIP, subtract accordingly.)

6. Assembly Steps

Below is a generic step-by-step approach to assembling this quadruplex’s shell.

1. Site Preparation & Piers

   • Excavate or drill holes.
   • Place sonotubes or precast piers.
   • Insert anchor bolts or steel brackets.

2. Place and Bolt Perimeter I-Beams

   • Lift each beam section onto the foundation piers.
   • Align pre-drilled holes with anchor bolts.
   • Torque to specification.

3. Install Vertical Stanchions

   • Raise each vertical I-beam or wide-flange column.
   • Bolt to the perimeter beams using bracket plates.
   • Ensure plumb alignment.

4. First-Floor SIP Installation

   • If building above ground, place SIP floor panels across the perimeter beams.
   • Secure with wood nailers or L-angles and heavy-duty screws.
   • Seal joints with expanding foam or SIP-approved tape to ensure air-tightness.

5. Second-Floor Perimeter I-Beams

   • Repeat the perimeter ring for the next level.
   • Bolt to the top of vertical stanchions.

6. Second-Floor SIP Installation

   • Install SIP floor panels for the upper level.
   • Fasten similarly as done on the first floor.

7. SIP Walls

   • Tilt-up or “stand” the wall panels around the perimeter.
   • Attach bottom edges to floor panels or steel ledger, top edges to the upper beams.
   • Seal panel joints.

8. Top Perimeter Beams & Roof SIPs

   • If included in your “dry-in,” add top perimeter beams or an upper ring to support roof SIPs.
   • Lift, align, and secure roof SIPs.

(At this point, you have a structure that is dried in if you add a temporary roof covering or if your SIP roofing includes some waterproof membrane, though in most cases a permanent roof membrane or covering is still needed.)

7. Cost Analysis (Dried-In) and Comparisons

7.1 SIP + Steel Dried-In Costs (Excluding Windows, Doors, and Final Roof Covering)

Let’s compile the main categories:

Cost per square foot (assuming 3,000 sq ft of living space, fully 2 stories, and the roof deck for dryness):

• Low-End: $47,980 ÷ 3,000 ≈ $16.00 per sq ft
• High-End: $88,686 ÷ 3,000 ≈ $29.56 per sq ft

If you exclude the roof SIPs for the immediate comparison (some designs might rely on standard roof trusses or not install SIP roof until later), you could subtract $7,500–$13,500 from the total. That might bring the range to roughly:

• $40,480 (low) to $75,186 (high), or $13.49 to $25.06 per sq ft.

7.2 Stick-Built Dried-In Costs (No Doors, No Windows, No Roof Covering)

To compare apples to apples, we consider a typical wood framing approach:

1. Concrete Foundation (Slab or Footings), ~$15,000–$25,000.
2. Wood Framing (walls, floors, rafters), ~$40,000–$65,000.
3. Fasteners & Sheathing (plywood/OSB, nails, etc.), ~$3,000–$5,000.

That puts a typical stick-built dried-in (minus doors, windows, roof finish) at around:

• $58,000 (low) to $95,000 (high).
• $58,000 ÷ 3,000 sq ft = $19.33/sq ft (low).
• $95,000 ÷ 3,000 sq ft = $31.67/sq ft (high).

7.3 Cost Comparison Summary

Conclusion from Table:

• At the dried-in stage (with or without roof SIPs included), SIP + Steel is still cheaper on a per-square-foot basis than stick-built.
• You also gain structural advantages, reduced on-site labor, and shorter overall build times.

8. Potential Challenges and Common Objections

8.1 Code Compliance and Permits

• Overseas SIPs may not carry the necessary ICC-ES or local code listings. You might need an engineer’s stamp, plus third-party testing to satisfy local building departments.
• Steel Frame requires an understanding of local wind/seismic codes. Some building officials are less familiar with residential steel designs.

8.2 Lack of Contractor Familiarity

• Steel Erection: Many small residential framing crews do not own or use steel-cutting tools, mag drills, or bolting equipment.
• SIP Installation: Although relatively straightforward, SIPs require different methods (e.g., splines, foam sealing, large panel handling).

8.3 Supply Chain Uncertainties

• Overseas SIP Shipping: May involve unpredictable shipping costs, potential tariffs, and longer lead times.
• Local SIP Production: Often priced higher than mass-produced stick-lumber, preventing large-scale adoption.

8.4 Connector and Fastener Details

• Stanchion-to-Beam Connection: Must be carefully designed with gusset plates or angle brackets, then bolted.
• Beam-to-Pier: Bolts must handle uplift, shear, and moment; an engineer’s input is crucial.

8.5 Perceived Risk and Tradition

• Builders and Lenders: Residential construction is conservative; “new methods” can raise skepticism.
• Appraisers: May not be familiar with valuing SIP + steel structures if the local market is predominantly stick-built.

9. Conclusion

This white paper has examined in detail the feasibility, cost, and benefits of using Structural Insulated Panels (SIPs) in combination with steel I-beams (wide-flange columns and beams) for a two-story, four-unit (quadruplex) residential structure. By zeroing in on the dried-in stage (excluding windows, doors, roofing membranes, and interior systems), we arrive at a realistic “shell cost.”

Key Conclusions:

1. Cost Advantages

   • SIP + Steel dry-in can be in the $13.50–$30 per sq ft range (depending on specifics), often cheaper than equivalent stick framing.

2. Speed of Assembly

   • SIPs arrive pre-cut, drastically reducing on-site labor and waste.
   • Steel beams can be pre-drilled for bolt-on connections, reducing field labor.

3. Quality and Performance

   • SIPs provide superior insulation and structural rigidity, reducing the need for additional bracing.
   • Steel frames do not warp or decay and are highly resistant to fire and pests.

4. Challenges

   • Code acceptance of overseas SIPs can be complex.
   • Skilled labor in steel + SIP assembly is harder to find, and the local trades are predominantly trained in wood.
   • The up-front engineering and planning can be more intensive than standard wood framing.

5. Promise for Affordable Housing

   • By scaling up to 20 or more quadruplexes, the volume purchase of steel beams (e.g., from O’Neal Steel) and large orders of SIPs (whether domestic or imported) can reduce per-unit costs.
   • Shorter build schedules mean reduced carrying costs for developers and less scheduling uncertainty.

In short, while the mainstream construction industry in the U.S. defaults to stick-built methods, SIP + steel offers a compelling alternative—faster, potentially cheaper, and more energy-efficient. The success of such a project hinges on careful engineering, cost analysis, and supply chain logistics (especially if sourcing SIPs from overseas).

10. Long References

Below are long-form web references that can be printed or saved to avoid link shortener problems:

1. Premier SIPs Manufacturer
   https://www.premiersips.com/

   • Provides information on domestic SIP design, code compliance, and pricing details.

2. Enercept SIPs
   https://www.enercept.com/

   • Another U.S.-based SIP supplier with examples and cost breakdowns.

3. O’Neal Steel (Steel Supplier)
   https://www.onealsteel.com/

   • A major steel distributor offering wide-flange beams, structural tube, plate, and more.

4. International Residential Code (IRC)
   https://codes.iccsafe.org/content/IRC2021P5

   • U.S. building code referencing structural requirements.

5. Structural Insulated Panel Association (SIPA)
   https://www.sips.org/

   • Trade organization with code acceptance resources, best practices, and case studies.

6. USDA: Precast Concrete Pier Systems
   https://www.fs.usda.gov/eng/pubs/pdfpubs/pdf07232814/pdf07232814.pdf

   • Discusses precast piers and their applications, though originally for different structures.

Compliance Standards

No compliance standards specified.

Manufacturer Specifications

No manufacturer specifications available.
